Technical Specifications

Brand	DELL
Server Model	Dell PowerEdge R740 Server
Form Factor	2U Rack
Processor Models	Two Intel Xeon Processor Scalable Family processors
No of Processors	2
Max Cores	56 Cores
Ram Type	DDR4
Support RAM’s	4GB, 8GB, 16GB, 32GB, 64GB, 128GB
Max Memory	3TB
Total Memory Slots	24 DIMM’s
Graphics Card	Nvidia Tesla P100, K80, K40, Grid M60, M10, P4, Quadro P4000, NVIDIA V100
Hard drives(hot-plug)	Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5” SAS/SATA HDD max 128TB
Operating System	Canonical Ubuntu Microsoft Windows Server Oracle Linux
PCI slots	8 PCIe Gen 3 slots
RAID controller	PERC H330, H730P, H740P, HBA330, H840, 12 Gbps SAS HBA RAID S140
Power supply	1600W, 2000W and 2400W, Gold 1100W Titanium 750W, Platinum 495W, 750W
