Technical Specification

BRAND	Dell
SERVER MODEL	Dell PowerEdge R7415 Rack Server
FORM FACTOR	2U
PROCESSOR MODELS	1x AMD EPYC processor, up to 32 cores
MAX CORES	32 cores
RAM TYPE	DDR4
SUPPORT DRIVES	SAS/SATA/NVMe
MAX MEMORY	16 DDR4 DIMMs, RDIMM, LRDIMM
GRAPHICS CARD	Matrox G200eR2 graphics card with 16 MB
SUPPORTED DRIVES	Front Drive Bays: Up to 24 x 2.5” SATA/SAS/NVMe or up to 12x 3.5” SAS/SATA HDD Rear Drive Bays: Up to 2×3.5” SAS/SATA HDD
OPERATING SYSTEM	Microsoft Windows Server® 2016 Red Hat® Enterprise Linux 7.4 VMware® vSphere 2016 U1 (ESXi 6.5 U1) Microsoft Windows Server® 2012 R2
PCIE SLOTS	Up to 4 x Gen3 slots; 3 x 16 lanes and 1 x 8 lanes.
RAID CONTROLLER	HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module External PERC (RAID): H840
POWER SUPPLY	Titanium 750W, Platinum 495W, 750W, 1600W, and 1100W 240HVDC 750W

Additional information

Brand	Dell
Form Factor	2U
Core Options	32
Processor Brand	AMD
RAM Type	DDR4
DIMM Slots	16 DDR4 DIMM
Drive bays	SATA/SAS/NVMe
Supported operating systems	Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.4, VMware vSphere 2016 U1 (ESXi 6.5 U1), and Microsoft Windows Server 2012 R2.
