Technical Specifications

Brand	Dell
Server Model	Dell PowerEdge R630 Rack Server
Form Factor	1U Rack Server
Processor Models	Intel Xeon E5-2600 v3 or v4 processors Family
No of Processors	2
Max Cores	44 Cores
Ram Type	DDR4
Support RAM’s	4GB, 8GB, 16GB, 32GB, 64GB
Max Memory	1.5 TB
Total Memory Slots	24 DIMM’s
Graphics Card	Matrox Graphics, Inc. G200eR2 PCI (102b:0534)
Hard drives(hot-plug)	24 x 1.8” SSD up to 23TB, with 0.96TB Hot-plug SATA SSD, 10 x 2.5” up to 18TB with 1.8TB hot-plug SAS HDD, 8 x 2.5” up to 14TB with1.8TB hot-plug SAS HDD
Operating System	Microsoft Windows Server Linux Server
PCI slots	Up to 3 PCIe 3.0 expansion slots
RAID controller	PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P PERC H830
Power supply	1100W DC power supply Titanium efficiency 750W AC power supply Platinum efficiency 495W, 750W, 1100W
