Huawei CloudEngine 12800 Data Center Switches

TRY 204,169.00TRY 264,169.00 (-23%)

In stock

  • Brand: Huawei
  • Form Factor: Modular Chassis
  • Models: CE12804S, CE12808S, CE12804, CE12808, CE12812, CE12816
  • Switching Capacity: Up to 178 Tbit/s (scalable to 1032 Tbps)
  • Security: Comprehensive security features including ACLs, IPSec, encryption, and DDoS protection
  • Use Cases: Large-scale data centers, cloud computing environments, high-performance computing (HPC), and service provider networks
  • Support: 24/7 technical support

Description

Are you in need of a future-proof & energy-efficient network solution for your business that can ensure excellent traffic control? The Huawei CloudEngine 12800 10-Gigabit Ethernet series is a highly suitable option for all of these needs. It offers switches with high bandwidth at a rate of 400Gbps per port and low latency ideal for managing a large traffic volume and response time respectively. A Huawei 12800 Switch provides 10G, 25G, 40G, 50G, and 100G ports per density, delivering scalability for massive networks. It supports Virtual Extensible LAN (VXLAN), EVPN, and segment routing which are crucial for next-generation data center networks. Huawei CE12800 switches come equipped with features like access control lists, IP source guards, and dynamic ARP inspection (DAI) to secure the network against various types of attacks. Along with all these technical features, other privileges like the fastest delivery to any city in Turkey, a 1-year warranty, comprehensive tech support, and live chat assistance are also provided as a bonus when you buy the desired switch at ServerBasket.

Optimized-Connectivity-with-Huawei-CloudEngine-12800-Series-Switches

Optimized Connectivity with Huawei CloudEngine 12800 Series Switches

Huawei’s CloudEngine 12804, 12808, and 12816 data center switches are high-performance models with support for up to 160 Tbps throughput. Specifically, these switches provide dense 100GE / 400GE interfaces, VXLAN technology for network virtualization, as well as compatibility with SDN, allowing the implementation of modern data centers.

Proactive Technical Solutions and Robust Warranty Coverage

The Huawei CE12800 Switch may rarely pose problems to its users, such as complicated network settings and compatibility with existing systems. Server Basket offers specific technical assistance to deal with such challenges and guarantee successful deployment of the switch into your network. Furthermore, all the switches are warranted for one year, this ensures that the customer gets a fully tested and reliable switch and free repair/replacement in case of any defects.

Proactive-Technical-Solutions-and-Robust-Warranty-Coverage

Huawei CloudEngine 12804S Switch

Switching capacity40/80 Tbit/s
Forwarding performance17,280 Mpps
Service slots4
Switching fabric module slots2
Maximum Power Supply6000W

Huawei CloudEngine 12808S Switch

Max Switching Capacity80/160 Tbit/s
Forwarding Performance34,560 Mpps
Number of Service Slots8
Switching Fabric Module Slots4
Maximum Power Supply12000W

Huawei CloudEngine CE12804 Switch

Max Switching Capacity40/80 Tbit/s
Forwarding Performance17,280 Mpps
Number of Service Slots4
Switching Fabric Module Slots6
Maximum Power Supply5400 W

Huawei CloudEngine CE12808 Switch

Max Switching Capacity80/160 Tbit/s
Forwarding Performance34,560 Mpps
Number of Service Slots8
Switching Fabric Module Slots6
Maximum Power Supply10800 W

Huawei CloudEngine CE12812 Switch

Max Switching Capacity120/240 Tbit/s
Forwarding Performance51,840 Mpps
Number of Service Slots12
Switching Fabric Module Slots6
Maximum Power Supply16200 W

Huawei CloudEngine CE12816 Switch

Max Switching Capacity160/320 Tbit/s
Forwarding Performance69,120 Mpps
Number of Service Slots16
Switching Fabric Module Slots6
Maximum Power Supply27000 W

Advanced Network Features and Specifications for High-Performance Systems

Airflow designStrict front-to-back
VirtualizationVirtual System (VS), Cluster Switch System (CSS), and Super Virtual Fabric (SVF)
Network virtualizationEVPN, VXLAN routing and bridging , M-LAG
Network convergenceDCBX, PFC, ETS, and FCoE
Traffic analysissFlow, NetStream
VLANQinQ, MUX VLAN, Default VLAN, and Adding access, trunk, and hybrid interfaces to VLANs
IP routingIPv4 dynamic routing protocols, such as RIP, OSPF, IS-IS, and BGP, IPv6 dynamic routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+
IPV6IPv6 Neighbor Discovery (ND), Path MTU Discovery (PMTU), TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6
QoSTraffic classification based on Layer 2, Layer 3, Layer 4, and priority information, Actions include ACL, CAR, and re-marking, Queue scheduling modes such as PQ, WFQ, and PQ+WRR, Congestion avoidance mechanisms, including WRED and tail drop, Traffic shaping
Security and management802.1x authentication, RADIUS and HWTACACS authentication for login users, Command line authority control based on user levels, preventing unauthorized users from using commands, Defense against MAC address attacks, broadcast storms, and heavy-traffic attacks, Ping and traceroute, Remote Network Monitoring (RMON)
Operating voltageAC: 90 V to 290 V, DC: -38.4 V to -72 V, HVDC: 240V
