Technical Specifications

Brand	DELL
Server Model	PowerEdge R7525
Form Factor	2U Rackmount
Processor Model	2nd or 3rd-Gen AMD EPYC CPU
No. of Processor Sockets	2
Max Cores	128 Cores
RAM Type	DDR4
Supported RAM’s	128GB, 64GB, 32GB, 16GB, and 8GB
Max Memory	4TB
Total Memory Slots	32
Supported Network	2 x 1GE LOM (Lights out Management) + OCP Mezz 3.0 (optional)
Supported Hard Drives (Hot-Plug)	Up to 24 SFF NVMe Up to 16 SFF SAS or SATA (SSD/HDD) and NVMe Up to 12 LFF SAS or SATA (Hard drive) 10k SAS SFF 2.4TB (SED/FIPS), 1.2TB (SED/FIPS), 1.8TB, 1.2TB, 600GB, 300GB 7.2k SATA SFF 2TB, 1TB 7.2k SATA LFF 10TB, 8TB, 6TB, 4TB, 2TB, 1TB 7.2k SAS LFF 8TB (SED FIPS), 4TB (SED FIPS), 10TB, 8TB, 6TB, 4TB, 2TB, 1TB
Supported Operating System	Canonical Ubuntu Citrix Hypervisor Microsoft Windows Server
PCIe Slots (Expansion Slots)	Up to 8 PCIe Gen4 slots
Supported RAID Controllers	12Gbps SAS HBA, PERC H345, H745, HBA345, and H840
Power Supply	2400W AC/HVDC 800W or 1400W Platinum
