Technical Specifications

Brand	DELL
Server Model	PowerEdge R7515
Form Factor	2U Rackmount
Processor Model	2nd or 3rd Gen AMD EPYC CPU
No. of Processor Sockets	1
Max Cores	64 Cores
RAM Type	DDR4
Supported RAM’s	128GB, 64GB, 32GB, 16GB, and 8GB
Max Memory	2TB
Total Memory Slots	16 DIMM’s
Supported Network	2 x 25GbE SFP28 2 x 10GbE SFP+ 2 x 10GbE BT 2 x 1GbE
Supported Hard Drives (Hot-Plug)	Up to 2 LFF” hot-plug SAS/SATA (HDD) Up to 8 LFF hot-plug SATA/SAS (HDD) Up to 12 LFF hot-plug SAS/SATA (HDD) Up to 24 SFF hot-plug SATA/SAS/NVMeSATA LFF 10TB, 8TB, 6TB, 4TB, 2TB, 1TB SAS LFF 10 TB, 8 TB, 4 TB, 2TB, 1TB, 8TB SED, 4TB SED SATA SFF 900 GB, 600 GB, 300 GB
Supported Operating System	Red Hat Enterprise Linux Citrix Hypervisor Microsoft Windows Server Canonical Ubuntu
PCIe Slots (Expansion Slots)	Up to 4: 2 Gen3 slots (1 x 8, 1 x16), and 2 Gen4 slots (2 x16 )
Supported RAID Controllers	12G SAS HBA, H740P, PERC HBA330, H840, H730P, H330
Power Supply	1600W Platinum, 1100W Platinum, 495W Platinum, 750W Titanium or Platinum
