Description

If you are searching for an enterprise-grade server to give a boost to your business with excellent performance and processing power, you must buy the HP DL360 G10 server. It is the best server that you will come across, which will help you manage data center deployment. The HP Proliant DL360 G10 Server is a two-socket server that offers excellent flexibility. Enjoy the built-in security feature, persistent memory, and better storage options with this server.

Buy the HP Proliant DL360 G10 server from ServerBasket if you need a solid and supporting database for virtualization and high-performance computing applications. Known to be one of the newest members of the HPE’s Gen10 family of scalable servers, it gives significantly improved performance than its predecessors. It provides excellent memory as its two Intel processors support six memory channels each. Moreover, you get various choices to customize the server as per your needs and workload requirements.

HP DL360 Gen 10 Server Price List:

Server Model	Memory	Storage	Cores	Price
HP DL360 G10 (Enterprise)	384GB (12 X 32GB) DDR4	2 x 600GB 2.5-inch 10K RPM	2 x 24 (48 Cores / 112 Threads)	USD 6,959
HP DL360 G10 (Business)	256GB (8 X 32GB) DDR4	2 x 600GB 2.5-inch 10K RPM	2 x 24 (48 Cores / 112 Threads)	USD 4,926
HP DL360 G10 (Growth)	128GB (4 X 32GB) DDR4	2 x 600GB 2.5-inch 10K RPM	2 x 10 (20 Cores / 40 Threads)	USD 3,972
HP DL360 G10 (Starter)	64GB (2 X 32GB) DDR4	2 x 600GB 2.5-inch 10K RPM	2 x 10 (20 Cores / 40 Threads)	USD 1,900

Dual Processor Performance for Mission-Critical Workloads

The HP Proliant DL360 G10 server can easily handle the mission-critical workloads of your business. It is equipped with Two Intel Xeon Scalable 8100/8200 series and Intel Xeon Scalable 3100/3200 series, which support six memory channels. You get to enjoy the dual-processor performance, which can seamlessly manage intensive workloads.

Flexible Drive Options for Need-based Storage

HP Proliant DL360 G10 server offers flexible drive options for need-based storage. There are 4-bay and 6-bay chassis configurations that you can choose from as per your storage requisites. Several Smart Array storage controller options can fulfill both internal and external storage needs.

Excellent Memory Performance

The HP Proliant DL360 G10 server features 24 DIMM slots and has a huge memory capacity of 3TB. Intel Xeon Scalable processor with up to 56 cores helps the server to give an excellent memory performance with memory speeds of up to 2666 MT/s.

Various Choices for Customization

You get customization options at an affordable HP DL360 G10 Server Price. Based on your workload requirements, you can refer to the HP DL360 G10 Server Quickspecs and pick the components you need. Option for customized configuration can meet your high-end specifications.

Supports Virtualization and HPC Applications

HP DL360 G10 server is the ideal choice for virtualization, which can independently run its operating systems and high-performance computing applications. ServerBasket also provides an HP DL360 G10 Server Manual, which explains the functions of the server.

Technical Specifications

Brand	HP
Server Model	HP DL360 Gen 10
Form Factor	1U Rack
Processor Models	Intel Xeon Scalable 8100 series, Intel Xeon Scalable 6100 series, Intel Xeon Scalable 5100 series, Intel Xeon Scalable 4100 series, Intel Xeon Scalable 3100 series.
No of Processors	2
Max Cores	56 Cores
Ram Type	DDR4
Support RAM’s	8GB, 16GB, 32GB, 64GB, 128GB
Max Memory	3TB
Total Memory Slots	24 DIMM’s
Graphics Card	Integrated Video Standard, Video modes up to 1920 x 1200@60Hz (32 bpp), 16MB Video Memory
Hard drives(hot-plug)	Hot Plug SFF SAS HDD 26.4 TB (8+2+1 x 2.4 TB), Hot Plug SFF SATA HDD 22 TB (8+2+1 x 2.0 TB), Hot Plug SFF SAS SSD 168.3 TB (8+2+1 x 15.3 TB), Hot Plug SFF SATA SSD 42.24 TB (8+2+1 x 3.84 TB)
Operating System	Microsoft Windows Server VMware Server Linux Server
PCI slots	PCIe 3.0 x16, PCIe 3.0 x8
RAID controller	RAID 0, RAID 1, RAID 10, RAID 5, RAID 6, RAID 50, RAID 60
Power supply	HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Product Information

Additional information

Brand	HP
Form Factor	1U
Core Options	10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 4, 6, 8
RAM Type	DDR4
RAM Capacity	3TB
Storage Capacity	168.3TB

Reviews (0)

Be the first to review “HP DL360 Gen10 Server”

Reviews

There are no reviews yet.

FAQ

Which processor models are used in the DL360 Gen10 server?

The HPE ProLiant DL360 Gen10 Server supports the Intel Xeon Scalable Processor Family with up to 28 cores, accommodating various models including Intel Xeon Platinum CPUs such as the 8260 2.4GHz/24‑core and 8268 2.9GHz/24‑core (part numbers: P02661-B21, P02670-B21), Intel Gold CPU models like 6258R 28-core/2.7GHz, 6252 24-core/2.1GHz, 6254 18-core/3.1GHz, 6246R 16-core/3.4GHz, 6226 12-core/2.7GHz, and 6250 8-core/3.9GHz (part numbers: P24488-B21, P02646-B21, P02649-B21, P24486-B21, P02601-B21, P23741-B21), Intel Xeon-Silver CPU models such as 4216 16-core/2.1GHz, 4214R 12-core/2.4GHz, 4210 10-core/2.2GHz, and 4215R 8-core/3.2GHz (part numbers: P02583-B21, P15977-B21, P02574-B21, P24479-B21), and Intel Xeon-Bronze CPU models like 3206R 8-core/1.9GHz and 3204 6-core/1.9GHz (part numbers: P15968-B21, P02565-B21).

How many maximum cores can DL360 Gen10 provide?

HPE DL360 Gen 10 server provides a maximum of 56 cores in a two-processor configuration, which helps the server to deliver excellent memory and overall performance.

What is the memory configuration for the DL360 Gen10 server?

The HPE DL360 Gen10 server boasts an impressive memory capacity of 3TB, equipped with 24 DIMM slots supporting maximum memory speeds of up to 2933MT/s. It accommodates various compatible memory modules including 2nd Generation Intel Xeon Scalable Series RDIMMs, DDR4-2933 CAS-21-21-21, available in Dual Rank models of 64GB, 32GB, and 16GB (part numbers: P00930-B21, P00924-B21, P00922-B21), as well as Single Rank models of 16GB and 8GB (part numbers: P00920-B21, P00918-B21). Additionally, for 1st Generation Intel Xeon Scalable Series, compatible RDIMMs of DDR4-2666 CAS-19-19-19 are available in Dual Rank 32GB and 16GB configurations (part numbers: 815100-B21, 835955-B21). For 2nd Generation, Intel Xeon Scalable Series supported LRDIMMs, DDR4-2933 CAS-21-21-21 of 128GB Quad Rank are available (part number: P11040-B21). Moreover, it supports Intel Optane HPE Persistent Memory of 100 Series, including 512GB and 128GB (part numbers: 835810-B21, 835804-B21)

What is the maximum storage capacity of this server?

The HP DL360 Gen10 server offers flexible storage options tailored to specific needs, with configurations including 4-bay and 8-bay chassis, providing a maximum internal storage capacity of up to 168.3 TB. Compatible hard disk drives and their capacities include Enterprise 12G SAS - SFF HDDs with sizes of 2.4TB, 1.8TB, and 1.2TB as well as Read Intensive 24G SAS - SFF SSDs with sizes of 15.36TB (part numbers: P28352-B21, P53562-B21, P28586-B21, P49045-B21), designed for use with Broadcom MegaRAID. Additionally, Read Intensive 6G SATA - SFF SSDs with sizes of 3.84TB and 960GB (part numbers: P40500-B21, P40498-B21), along with Enterprise 12G SAS - SFF HDDs in sizes of 2.4TB and 1.2TB (part numbers: 881457-B21, 872479-B21). Read Intensive 12G SAS - SFF SSDs are also compatible, with sizes of 7.68TB, 3.84TB, and 960GB (part numbers: P37003-B21, P49035-B21, P36997-B21). Furthermore, High-Performance NVMe Gen4 Read Intensive SSDs are supported, with sizes of 7.68TB, 3.84TB, and 1.92TB (part numbers: P51456-B21, P51454-B21, P51452-B21).

Is a 1200W power supply sufficient for the DL360 Gen10? If not how much power does it need?

No, a 1200W power supply is not sufficient for the HPE DL360 Gen10 server as it requires 800W and 1600W Flex slot hot-plug Low halogen kit for supplying power.

Which power supplies are compatible with the ProLiant DL360 Gen10 Server?

The HPE ProLiant DL360 Gen10 Server supports up to 2 Power Supplies for redundant power. Compatible Low Halogen Flex Slot PSUs include Platinum models of 1600W, 800W, and 500W (part numbers: 830272-B21, 865414-B21, and 865408-B21), as well as Titanium models of 1000W and 800W (part numbers: P03178-B21, 865438-B21). Additionally, Universal and -48VDC options of 800W are available (part numbers: 865428-B21, 865434-B21).

What support services are provided by Server Basket?

ServerBasket provides complete and professional technical support services. The support features include round-the-clock tech and installation assistance, free demo sessions, a 7-day return policy, a three-year guarantee, same-day shipping, and throughout-India delivery services. Customers get consulting from the expert team for pre-sales decisions, issue troubleshooting, software support, and configuration from our highly qualified support staff.
