Technical Specifications

Brand	HP
Server Model	ProLiant DL365 Gen11
Form Factor	1U Rackmount
Processor Model	4th Gen AMD EPYC CPUs
No. of Processor Sockets	2
Max Cores	192 Cores
RAM Type	DDR5
Max Memory	6.0 TB
Total Memory Slots	24 DIMM’s
Supported Graphics Card	Upto 1920 x 1200@60Hz (32 bpp)
Supported Hard Drives (Hot-Plug)	Hot Plug 2.5-inch SAS HDD 24 TB, 2.4 TB x (8+2) Hot Plug 2.5-inch SATA HDD 20 TB, 2.0 TB x (8+2) Hot Plug 2.5-inch SAS SSD 76.8 TB, 7.68 TB x (8+2) Hot Plug 2.5-inch SATA SSD 76.8 TB, 7.68 TB x (8+2) Hot Plug 2.5-inch NVMe PCIe U.3 SSD 153.6 TB, 15.36 TB x (8+2)
Supported Operating System	Windows Server 2019 Windows Server 2022 Red Hat Enterprise Linux (RHEL) 9.0
PCIe Slots (Expansion Slots)	3 x PCIe 5.0 Slots
Supported RAID Controllers	HPE Smart Array E208e-p SR Gen10, MR216i-p Gen11 x16 Controller MR216i-o Gen11 x16 Controller MR408i-o Gen11 x8 Controller MR416i-o Gen11 x16 Controller MR416i-p Gen11 x16 Controller SR932i-p Gen11 x32 Controller
Reduntant Hot-plug Power Supply	Hot Plug 800W Platinum Low Halogen Hot Plug 1600W Platinum Low Halogen
