Huawei CloudEngine 12800 Data Center Switches

 9,537,089 10,013,989 (-5%)

In stock

  • Brand: Huawei
  • Form Factor: Modular Chassis
  • Models: CE12804S, CE12808S, CE12804, CE12808, CE12812, CE12816
  • Switching Capacity: Up to 178 Tbit/s (scalable to 1032 Tbps)
  • Security: Comprehensive security features including ACLs, IPSec, encryption, and DDoS protection
  • Use Cases: Large-scale data centers, cloud computing environments, high-performance computing (HPC), and service provider networks
  • Support: 24/7 technical support

Description

Does your business or data center face challenges of network congestion, inadequate performance, or the absence of sophisticated network solutions? The Huawei 12800 Switch can effectively manage these challenges with various advanced characteristics. They equip high-density 10GE, 25GE, 40GE, and 100-Gigabit Ethernet ports to resolve the congestion concern by achieving high bandwidth and throughput. The distributed hardware design of Huawei CE12800 provides high levels of scalability and switching performance with the minimum latency, the current data center demands. The Huawei CloudEngine 12800 10-Gigabit Ethernet also comes equipped with the iMaster NCE (Network Cloud Engine) from Huawei, which is featured as a robust network management solution that includes automated networking, smart monitoring, and real-time diagnostics and network analysis solutions. Furthermore, at ServerBasket, you get free and fast delivery to Lagos, Kano, Ibadan, and other Nigerian cities, easy, affordable installment plans, and a 30-day credit option to enable you to get the best out of the data center performance and backup services.

Model-Overview-and-Performance-Features

Model Overview and Performance Features

The Huawei CE12800 Switch series comprises models like the CloudEngine 12800-8E, CloudEngine 12800-32, CloudEngine 12800-16, and CloudEngine 12800-4X models which support up to 100GE ports and provide fast switching capability. These high-performance models offer high bandwidth, flexible topology, and low latency suitable for demanding network environments.

Professional Tech Support Service With Cost-effective Solution

ServerBasket offers professional tech support for Huawei CE12800 problems, including low MAC address table size, improper multicast control problems, automation problems in Huawei 12800 Switch, and high end-to-end link delay problems. Also, we have relatively low prices for our products that will help make necessary upgrades for your network’s performance more cost-effective.

Professional-Tech-Support-Service-With-Cost-effective-Solution

Huawei CloudEngine 12804S Switch

Switching capacity40/80 Tbit/s
Forwarding performance17,280 Mpps
Service slots4
Switching fabric module slots2
Maximum Power Supply6000W

Huawei CloudEngine 12808S Switch

Max Switching Capacity80/160 Tbit/s
Forwarding Performance34,560 Mpps
Number of Service Slots8
Switching Fabric Module Slots4
Maximum Power Supply12000W

Huawei CloudEngine CE12804 Switch

Max Switching Capacity40/80 Tbit/s
Forwarding Performance17,280 Mpps
Number of Service Slots4
Switching Fabric Module Slots6
Maximum Power Supply5400 W

Huawei CloudEngine CE12808 Switch

Max Switching Capacity80/160 Tbit/s
Forwarding Performance34,560 Mpps
Number of Service Slots8
Switching Fabric Module Slots6
Maximum Power Supply10800 W

Huawei CloudEngine CE12812 Switch

Max Switching Capacity120/240 Tbit/s
Forwarding Performance51,840 Mpps
Number of Service Slots12
Switching Fabric Module Slots6
Maximum Power Supply16200 W

Huawei CloudEngine CE12816 Switch

Max Switching Capacity160/320 Tbit/s
Forwarding Performance69,120 Mpps
Number of Service Slots16
Switching Fabric Module Slots6
Maximum Power Supply27000 W

Advanced Network Features and Specifications for High-Performance Systems

Airflow designStrict front-to-back
VirtualizationVirtual System (VS), Cluster Switch System (CSS), and Super Virtual Fabric (SVF)
Network virtualizationEVPN, VXLAN routing and bridging , M-LAG
Network convergenceDCBX, PFC, ETS, and FCoE
Traffic analysissFlow, NetStream
VLANQinQ, MUX VLAN, Default VLAN, and Adding access, trunk, and hybrid interfaces to VLANs
IP routingIPv4 dynamic routing protocols, such as RIP, OSPF, IS-IS, and BGP, IPv6 dynamic routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+
IPV6IPv6 Neighbor Discovery (ND), Path MTU Discovery (PMTU), TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6
QoSTraffic classification based on Layer 2, Layer 3, Layer 4, and priority information, Actions include ACL, CAR, and re-marking, Queue scheduling modes such as PQ, WFQ, and PQ+WRR, Congestion avoidance mechanisms, including WRED and tail drop, Traffic shaping
Security and management802.1x authentication, RADIUS and HWTACACS authentication for login users, Command line authority control based on user levels, preventing unauthorized users from using commands, Defense against MAC address attacks, broadcast storms, and heavy-traffic attacks, Ping and traceroute, Remote Network Monitoring (RMON)
Operating voltageAC: 90 V to 290 V, DC: -38.4 V to -72 V, HVDC: 240V
