Technical Specifications

Brand	HPE
Server Model	ProLiant DL360 Gen10 Plus
Form Factor	1U Rackmount
Processor Models	3rd Gen Intel Xeon Scalable Processors Intel Xeon Scalable 4300 series Intel Xeon Scalable 6300 series Intel Xeon Scalable 8300 series
No of Processors	2
Max Cores	80 Cores (40 cores per Socket)
Ram Type	DDR4
Support RAM’s	8GB, 16GB, 32GB, 64GB, 128GB, 192GB, or 256GB
Max Memory	8.0TB
Total Memory Slots	32 DIMM’s
Supported Hard Drives (Hot-plug)	Up to 4 LFF SAS/SATA HDDs or SSDs Up to 10 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 Hot Plug SFF SAS HDD 24.0 TB 8+2 x 2.4 TB Hot Plug SFF SATA HDD 20.0 TB 8+2 x 2.0 TB Hot Plug SFF SAS SSD 153.0 TB 8+2 x 15.3 TB Hot Plug SFF SATA SSD 76.8 TB 8+2 x 7.68 TB Hot Plug SFF NVMe PCIe SSD 153.6 TB 8+2 x 15.36 TB Hot Plug LFF SAS HDD 72.0 TB 4 x 18 TB Hot Plug LFF SATA SSD 30.72 TB 4 x 7.68 TB
PCIe slots	3 PCIe Gen4 Slots
Supported RAID Controllers	Broadcom MR216i-a Tri-Mode Controller for HPE Gen10 Plus Broadcom MR216i-p Tri-Mode Controller for HPE Gen10 Plus HPE Smart Array E208i-a SR Gen10 Controller HPE Smart Array E208i-a SR G10 LH Controller HPE Smart Array E208i-p SR Gen10 Controller HPE Smart Array E208e-p SR Gen10 Controller Microchip SR932i-p Tri-Mode Controller for HPE Gen10 Plus Microchip SR416i-a Tri-Mode Controller for HPE Gen10 Plus Broadcom MR416i-p Tri-Mode Controller for HPE Gen10 Plus Broadcom MR416i-a Tri-Mode Controller for HPE Gen10 Plus HPE Smart Array P408i-a SR Gen10 Controller HPE Smart Array P408i-a SR G10 LH Controller HPE Smart Array P408i-p SR Gen10 Controller HPE Smart Array P408e-p SR Gen10 Controller HPE Smart Array P816i-a SR Gen10 Controller HPE Smart Array P816i-a SR G10 LH Controller
Power supply	HPE 500W Flex Slot Platinum Hot Plug HPE 800W Flex Slot Platinum Hot Plug HPE 1600W Flex Slot Platinum Hot Plug
