Huawei CloudEngine 12800 Data Center Switches
ETB 666,219.00ETB 699,529.00 (-5%)
- Brand: Huawei
- Form Factor: Modular Chassis
- Models: CE12804S, CE12808S, CE12804, CE12808, CE12812, CE12816
- Switching Capacity: Up to 178 Tbit/s (scalable to 1032 Tbps)
- Security: Comprehensive security features including ACLs, IPSec, encryption, and DDoS protection
- Use Cases: Large-scale data centers, cloud computing environments, high-performance computing (HPC), and service provider networks
- Support: 24/7 technical support
Description
Do you find yourself struggling to implement fast and dependable data center network solutions? Huawei CloudEngine 12800 10-Gigabit Ethernet switches are created to fulfill your requirements by providing the best performance and optimum scalability. These switches come equipped with state-of-the-art hardware and software enhancements offering a density of up to 768 x 100GE full line-rate ports, ideal for high bandwidth applications in large-scale network settings. Due to its dense port options, modular chassis, and rigid design, the CloudEngine 12800 series is perfect for enterprises that need to upgrade their network’s performance and reliability. The CloudEngine 12800 series also supports more advanced routing protocols like BGP, OSPF, and IS-IS, further boosting its capacity to handle complicated routing structures. Our extensive delivery services cover all parts of Ethiopia, from Addis Ababa to Dire Dawa, Mekelle, and other regions where you may be operating your business. We also provide additional services, such as an easy return policy, EMI options, a 1-year warranty, etc.
Customizable CloudEngine 12800 Series for Varied Business Needs
The Huawei CE12800 series switches can be customized based on your network infrastructure needs. Some models available with us include CloudEngine 12808, 12812, and 12816, each designed to offer solutions for different scenarios. ServerBasket offers these multi-port switches in various speed variants to facilitate convenient and efficient network connectivity for enterprises and data centers.
Reliable Support & Flexible EMI Plans
We guarantee the smooth functioning of your Huawei CloudEngine 12800 switches by solving problems such as the mismatch of the duplex, software or firmware issues, and improper configurations. Moreover, there are easy EMI plans available so that you do not feel the financial burden. Keep your network always up and running with these high-end switches.
Huawei CloudEngine 12804S Switch
Switching capacity | 40/80 Tbit/s |
---|---|
Forwarding performance | 17,280 Mpps |
Service slots | 4 |
Switching fabric module slots | 2 |
Maximum Power Supply | 6000W |
Huawei CloudEngine 12808S Switch
Max Switching Capacity | 80/160 Tbit/s |
---|---|
Forwarding Performance | 34,560 Mpps |
Number of Service Slots | 8 |
Switching Fabric Module Slots | 4 |
Maximum Power Supply | 12000W |
Huawei CloudEngine CE12804 Switch
Max Switching Capacity | 40/80 Tbit/s |
---|---|
Forwarding Performance | 17,280 Mpps |
Number of Service Slots | 4 |
Switching Fabric Module Slots | 6 |
Maximum Power Supply | 5400 W |
Huawei CloudEngine CE12808 Switch
Max Switching Capacity | 80/160 Tbit/s |
---|---|
Forwarding Performance | 34,560 Mpps |
Number of Service Slots | 8 |
Switching Fabric Module Slots | 6 |
Maximum Power Supply | 10800 W |
Huawei CloudEngine CE12812 Switch
Max Switching Capacity | 120/240 Tbit/s |
---|---|
Forwarding Performance | 51,840 Mpps |
Number of Service Slots | 12 |
Switching Fabric Module Slots | 6 |
Maximum Power Supply | 16200 W |
Huawei CloudEngine CE12816 Switch
Max Switching Capacity | 160/320 Tbit/s |
---|---|
Forwarding Performance | 69,120 Mpps |
Number of Service Slots | 16 |
Switching Fabric Module Slots | 6 |
Maximum Power Supply | 27000 W |
Advanced Network Features and Specifications for High-Performance Systems
Airflow design | Strict front-to-back |
---|---|
Virtualization | Virtual System (VS), Cluster Switch System (CSS), and Super Virtual Fabric (SVF) |
Network virtualization | EVPN, VXLAN routing and bridging , M-LAG |
Network convergence | DCBX, PFC, ETS, and FCoE |
Traffic analysis | sFlow, NetStream |
VLAN | QinQ, MUX VLAN, Default VLAN, and Adding access, trunk, and hybrid interfaces to VLANs |
IP routing | IPv4 dynamic routing protocols, such as RIP, OSPF, IS-IS, and BGP, IPv6 dynamic routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+ |
IPV6 | IPv6 Neighbor Discovery (ND), Path MTU Discovery (PMTU), TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6 |
QoS | Traffic classification based on Layer 2, Layer 3, Layer 4, and priority information, Actions include ACL, CAR, and re-marking, Queue scheduling modes such as PQ, WFQ, and PQ+WRR, Congestion avoidance mechanisms, including WRED and tail drop, Traffic shaping |
Security and management | 802.1x authentication, RADIUS and HWTACACS authentication for login users, Command line authority control based on user levels, preventing unauthorized users from using commands, Defense against MAC address attacks, broadcast storms, and heavy-traffic attacks, Ping and traceroute, Remote Network Monitoring (RMON) |
Operating voltage | AC: 90 V to 290 V, DC: -38.4 V to -72 V, HVDC: 240V |
